Controlling optical absorption in metamaterial absorbers for plasmonic solar cells
|Michigan Tech's Open Sustainability Technology Lab.
Wanted: Students to make a distributed future with solar-powered open-source 3-D printing and recycling.
Pearce Publications: Energy Conservation • Energy Policy • Industrial Symbiosis • Life Cycle Analysis • Materials Science • Open Source • Photovoltaic Systems • Solar Cells • Sustainable Development • Sustainability Education
Source[edit | edit source]
- Wyatt Adams, Ankit Vora, Jephias Gwamuri, Joshua M. Pearce, Durdu Ö. Guney. Controlling optical absorption in metamaterial absorbers for plasmonic solar cells. Proc. SPIE 9546, Active Photonic Materials VII, 95461M (August 31, 2015); doi:10.1117/12.2190396. open access
Abstract[edit | edit source]
Metals in the plasmonic metamaterial absorbers for photovoltaics constitute undesired resistive heating. However, tailoring the geometric skin depth of metals can minimize resistive losses while maximizing the optical absorbance in the active semiconductors of the photovoltaic device. Considering experimental permittivity data for InxGa1-xN, absorbance in the semiconductor layers of the photovoltaic device can reach above 90%. The results here also provides guidance to compare the performance of different semiconductor materials. This skin depth engineering approach can also be applied to other optoelectronic devices, where optimizing the device performance demands minimizing resistive losses and power consumption, such as photodetectors, laser diodes, and light emitting diodes.
