Page 1 - Installation (not to scale)

This document gives schematic drawings of the assembly and operation of a wind powered water pump. The drawings are accompanied by a list of parts and materials used in the pumps manufacturing.

Publisher[edit | edit source]

Brace Research Institute
MacDonald College
McGill University
Ste. Anne de Bellevue 800
Quebec, Canada
H9X 1CO
1977

Publication Number T-114 Go back to AT Sourcebook

Installation[edit | edit source]

Page 1 - Installation (not to scale)

Assembly[edit | edit source]

Page 2 - Assembly (not to scale)
Page 3 - Assembly

Piston and Piston Rod[edit | edit source]

Page 4 - Piston Rod (not to scale)
Page 5 - Piston (not to scale)

Washers and Piston Head[edit | edit source]

Page 6 - Schematic of Rubber Washer and Steel plate (not to scale)
Page 7 - Schematic of Black Steel Plates

Operation[edit | edit source]

Page 8 - Pump Operational Steps

Parts and Materials[edit | edit source]

Page 9 - List of Parts and Materials

List of Parts and Materials[edit | edit source]

  • 36 - Nut Bored at 8mm
  • 34 - Round HD-Screw 4mm
  • 32 - Nut 8mm
  • 30 - Iron Rod 8mm
  • 28 - Steel Plate 4mm
  • 26 - Steel Plate 4mm
  • 24 - Rubber Washer 5mm
  • 22 - Rubber Washer 5mm
  • 20 - Black Steel Plate 4mm
  • 18 - Black Steel Plate 4mm
  • 16 - Coupling 90mm/100mm
  • 14 - Galv. Pipe 33mm/42mm
  • 12 - Galv. Pipe 80mm/90mm

Discussion[View | Edit]

This page could be improved by rotating the image files before uploading them.

Also, drawings seem to me missing many bill of materials callouts and part detail design.
