About this device
Keywords 3D printing, OSHE growbot, wire sensor holder, Plastic
Uses agriculture, development, industry
Authors Erica Umlor
Status Designed
Prototyped
Made? Yes
Replicated? No
Designed in United States
Affiliations MTU
MOST
Cost USD $ 0.06
SDGs SDG02 Zero hunger
SDG09 Industry innovation and infrastructure
License data
Hardware CC BY-SA 4.0
Instructions data
Manufacturing files https://www.youmagine.com/designs/wire-sensor-holder
Translation data

Project developed by Erica Umlor

Related Pages:

Abstract[edit | edit source]

This is for my GrowBot project for senior design (Both project pages can be found above in related pages). The length is customizable and a wire can fit in the channel and be fastened with a small zip tie in the slot half way down the shaft. The holes can also be fastened together with a zip tie. The fit should be stiff so that you can adjust the angles and they will stay put. This project will help hold a wire that has an inductor on the end to sense a frequency induced wire that is burried under ground. It will be attached to the frame of the robot on the front and can be folded up when not in use.


Bill Of Materials[edit | edit source]

Part Price Quantity
Any 3D Filament $15.00 - $20.00 1

All .stl and .scad files are here: [YouImagine Wire Sensor Holder]

Tools Needed[edit | edit source]

  1. MOST Delta RepRap or similar RepRap 3-D printer

Technical Specifications and Assembly Instructions[edit | edit source]

This protoype is printed in PLA and has 20% infill. The print time depends on the length that you choose. The minimum length of 4 cm took about 15 minutes and the ends together took about 20 minutes. For assembly, use regular sized zip ties (white) to connect the different holders. Use small zip ties (dark green) to fasten the wire into the slot. Make sure when fastening in the wire that it has enough slack and doesn't pull on it when bending the parts.

Cost Savings[edit | edit source]

  1. Cost to print 4 cm Holder: $0.06
  2. Cost to print Ends: $0.06
  3. There is no commercial product available as of Decemeber 2020

Benefited Communities[edit | edit source]
