TissueDB/Simulators/Cricothyrotomy Simulator (Aho)

From Appropedia


General Information

Anatomical reference: laryngeal structures (1) thyroid cartilage, (2) cricothyroid ligament, (3) cricoid cartilage, (4) trachea, with (A) cricothyrotomy and (B) tracheostomy access points labelled. Image by PhilippN, CC BY-SA 3.0 via Wikimedia Commons; based on Gray's Anatomy plate 951.

This task trainer teaches emergency cricothyrotomy — the airway of last resort in a "can't intubate, can't ventilate" situation — on a layered neck model built from household materials. The trainee palpates the laryngeal landmarks, makes a midline skin incision, exposes and bluntly perforates the cricothyroid membrane between the thyroid and cricoid cartilages, and inserts an endotracheal tube into the airway.[1]

Field Details
General Information Low-fidelity, low-cost task trainer for emergency cricothyrotomy, constructed from household and recycled materials. Source: Aho et al., Journal of Surgical Education, 2015.[1]
Features and Basic Operation A low-fidelity, very low-cost emergency-cricothyrotomy task trainer built from household and recycled materials. It reproduces the airway landmarks the procedure needs — the thyroid cartilage, the cricoid cartilage, and the trachea and larynx beneath overlying soft tissue and skin — so the laryngeal landmarks can be found by palpation and the cricothyroid membrane, the gap between the two cartilages, incised to reach the airway. Its very low cost makes it easy to reproduce in quantity, including in resource-limited settings.[1]
Current Development Status Built and tested; peer-reviewed (J Surg Educ, 2015), with a reported degree of construct validity.[1]
Estimated Build Time and Cost Not stated by Aho et al. 2015., Under US$0.10
Specialized Tools and Equipment Procedure instruments the model is used with (Aho et al. 2015): a clamp to spread and hold open the cricothyroid membrane, an endotracheal tube (inserted, twisted into place, and the cuff inflated), and an oxygen source with end-tidal CO2 confirmation for the final step. The source does not name the instrument used for the initial midline incision.[1]
Version Single model as described in Aho et al. (2015); no version designation is stated in the source.[1]
Development Team Contact Information Johnathon M. Aho, MD and colleagues (Cornelius A. Thiels, Yazan N. AlJamal, Raaj K. Ruparel, Phillip G. Rowse, Stephanie F. Heller, and David R. Farley), Department of Surgery, Mayo Clinic, Rochester, Minnesota. Corresponding author: David R. Farley, MD (farley.david@mayo.edu) (Aho et al. 2015).[1]

Tissues

Tissue Qty Material Cost Notes
Skin 1 piece Fabric — The model's outer skin layer.
Soft tissue (fat and muscle) 1 Styrofoam tubing — Soft-tissue layer between the skin and the airway.
Thyroid cartilage 1 Cardboard (shaped piece) — Upper (superior) laryngeal landmark.
Cricoid cartilage 1 Zip tie (cable tie) — Lower (inferior) laryngeal landmark, below the thyroid cartilage.
Trachea and larynx 1 Cardboard tube (toilet paper roll) — Airway core and lumen beneath the overlying layers.


Structural Parts

Part Name Qty Material Cost Notes
Tape — Tape (type not specified in source) — Fixes the cardboard thyroid cartilage to the Styrofoam.


Build Instructions

Phase 1: Assemble the cricothyrotomy model


Empty toilet paper roll. Aho et al. (2015) use such a cardboard tube as the trachea-and-larynx core.[2]


Plastic zip ties. Aho et al. (2015) place one circumferentially as the cricoid-cartilage landmark.[3]


Woven cotton cloth. Aho et al. (2015) wrap fabric over the assembly as the skin layer.[4]


  1. Obtain an empty toilet paper roll (cardboard tube) because Aho et al. use it as the trachea-and-larynx core.[1]
  2. Slide Styrofoam tubing over the toilet paper roll because it simulates the soft tissue overlying the airway.[1]
  3. Cut a separate piece of cardboard into the shape of the thyroid cartilage and tape it to the Styrofoam in the superior position, because the cardboard represents the thyroid-cartilage landmark.[1]
  4. Place a zip tie circumferentially around the Styrofoam just below the cardboard thyroid cartilage because it represents the cricoid cartilage.[1]
  5. Wrap fabric over the whole assembly because it represents the skin the trainee incises first.[1]
