Grid Architecture for Energy Ladder Products and Services

Grid Architecture

Grid architecture describes the basic equipment functions, types, and sizes that provide utility infrastructure to end users. In the history of electric utility companies serving specific geographic territories, monopoly companies determined the basic infrastructure components used to deliver services to their customers. This includes all basic equipment components, like poles, wires, and transformers, plus the associated metering, and communications and control technologies. Each type of utility (electric, natural gas, water, wastewater, telecommunications, broadband, etc.) has its own grid architecture, but it is also important to understand that multiple utility infrastructures depend on one another for successful operations. For example, all utilities are increasintly dependent on communications systems, and water utilities are intertwined with energy utilities in multiple ways.^[1]

Utility infrastructure and regulations are now beginning adapting to many innovations in equipment and functions. Most notably, there are now all kinds of distributed energy supply- and demand-management resources, including multiple energy storage technologies, available at vastly different scales, and sensors and controls to better manage both supply and demand flexibility. These new distribution-scale technologies mean that new kinds of grid architecture are now available for introduction. [See especially U.S. Department of Energy, Office of Electricity, 2022 and 2019, in references below.]

In the past century, grid architecture for multiple utility services almost always included facilities serving large geographic territories. The technologies grew in capacity until the utilities were reliant on a variety of highly-centralized, large-scale components serving many thousands of customers. Primary examples include gigawatt-scale electric generators, serving customers that are interconnected via hundreds or thousands of miles of high-voltage electric transmission. At the distribution network level, customers were served by wires and transformers intended to provide services to each customer for 50 Ampere (50Amp, or 50A) service, and then growing to 100A or 200A service per residential customer. Commercial customer services for the smallest businesses were served at the same residential power and energy levels, but medium or large commercial customers were and are now most often served at higher levels. Distribution circuits were typically constructed at what are nominally 4kV, 8kV, or 13.2kV levels. Larger commercial, institutional, and industrial customers typically have been served at higher and higher voltages, known as subtransmission (such as 38kV, 69kV) and transmission (such as 138kV, 240kV, 345kV, or 500kV). [Need one or two best citations for learning more about the U.S. electrical infrastructure here.]

However, much more attention is now being paid to highly distributed resources (serving individual end users, small clusters of users, neighborhoods, small villages, and various kinds of campuses). These same technologies can also be deployed to serve remote communities, potentially including services for many of the world's estimated one-million populated islands.^[2] Some such facilities are already serving an estimated 1 billion electricity consumers, using remote, off-grid facilities which might never be interconnected with a wide-area grid, or might not be interconnected for many years. [cite Gogla annual report here]. The World Bank estimates that as many as 200,000 remote mini- and micro-grids are needed to serve customers who might never receive access to a wide area grid, or at a minimum for those that are not likely to have access in the coming decade.^[3]

These circumstances are leading to increasing concerns about what resources are needed to serve differently situated customers. A particular concern is to design utility rates so that all customers might appropriate contributions to the utility infrastructures needed to provide them with safe, reliable, and resilent utility services, in keeping with each customer’s individual infrastructure needs, their energy and power utilization, and their willingness and economic opportunities for making contributions to ensure continuation of services to themselves and their communities. Tension exists between rate designs and the possibilities for customers to "defect" from participating in the support of specific utility services.^[4]

The essence of the "energy ladder" concept is that customers who previously lacked them should be afforded the opportunity to obtain access to clean and modern energy technologies and services, in small and gradual ladder-like "steps." Each subsequent step up the energy ladder can lead to improved outcomes in terms of economic growth and prosperity. This concept is frequently discussed in conjunction with the United Nations Sustainable Development Goal #7 [SDG7]. That goal is intended to "ensure access to affordable, reliable, sustainable and modern energy for all." [See Appropedia on Sustainable Develoopment Goals].

The conceptual overview presents the "Energy Ladder" concept, seven at orders of magnitude ranging from "no service" to single-digit watts (in what is often called a "solar lantern"), and then upwards in scale to include consideration of the smallest mini and microgrids, up to the largest microgrids for major campuses or whole communities. Even larger wide area grids have been serving customers at greater orders of magnitude.

As Stanton and Nordman (2017) explain:

There is an opportunity for all utilities to create value for their stakeholders by enabling and implementing well-designed energy ladders, representing sequences of products and services that lead to increasing well-being for customers that are presently unserved or underserved.
