File:DS012 Image CAD.jpg
Size of this preview: 800 × 549 pixels. Other resolution: 837 × 574 pixels.
Original file (837 × 574 pixels, file size: 27 KB, MIME type: image/jpeg)
CAD image of the Fixed Handrail
| Date created | October 4, 2018 |
|---|---|
| Author | Field Ready |
| License | CC-BY-4.0 |
| Date uploaded | September 4, 2026 |
| Uploader | Charles Vincent Barrete |
| Source | Field Ready |
