File:TissueDB-Sim-Wound Packing Simulator-Build-12b-Half Pipes Placed.png
Size of this preview: 542 × 600 pixels. Other resolution: 650 × 719 pixels.
Original file (650 × 719 pixels, file size: 261 KB, MIME type: image/png)
Step 12: PVC half-pipes placed in position. Source: PDF page 15. Part of TissueDB/Simulators/Wound_Packing_Simulator.
| Date created | Unknown |
|---|---|
| Author | Unknown |
| Date uploaded | February 28, 2026 |
| Uploader | Arturo Pelayo |
| License | Unknown |
