File:Assembly Process.jpg
Size of this preview: 600 × 600 pixels. Other resolution: 1,800 × 1,800 pixels.
Original file (1,800 × 1,800 pixels, file size: 389 KB, MIME type: image/jpeg)
Usage of the cable stripper to prepare the cable ends for crimping with the cable lugs. Mount and crimp the cable lugs using the crimping tool.
| Date created | May 15, 2025 |
|---|---|
| Author | Sarahmariaj |
| Date uploaded | October 29, 2025 |
| Uploader | Sarahmariaj |
| Source | Own work |
| License | CC-BY-SA-4.0 |
