A schematic showing the grid and filler material/setup of a lead-acid battery. The image was made based on http://www.autoshop101.com/forms/hweb3.pdf and the book "Zo werkt uw auto" by Rien Tholenaar & Carel Zaal. The latter containing an image showing which cells of the grid were filled with sponge lead/lead oxide. Not sure though whether both panels have this cell pattern or whether they need to be mirrored, ...
File history
Click on a date/time to view the file as it appeared at that time.
| Date/Time | Thumbnail | Dimensions | User | Comment | |
|---|---|---|---|---|---|
| current | 08:31, 30 July 2010 | | 773 × 474 (27 KB) | KVDP (talk | contribs) | lead oxide needed to be lead-tetroxide (since it's red). Both are used though in SLI lead-acid batteries |
| 12:03, 22 July 2010 |  | 773 × 474 (27 KB) | KVDP (talk | contribs) | A schematic showing the grid and filler material/setup of a lead-acid battery. The image was made based on http://www.autoshop101.com/forms/hweb3.pdf and the book "Zo werkt uw auto" by Rien Tholenaar & Carel Zaal. The latter containing an image showing wh |
